項目Project

參數Parameter

混凝土輸送泵型號Concrete transfer pump model

40

理論混凝土輸送量

Theoretical concrete conveying capacity

45 m³/h

主油泵排量Main oil pump displacement

112 ml/r

理論混凝土攪拌機攪拌量

Theoretical concrete mixer mixing amount

25-30 m³/h

混凝土攪拌機提升斗容積

Concrete mixer lift bucket volume

800L

混凝土攪拌機進料容量

Concrete mixer feed capacity

800 L

混凝土攪拌機出料容量

Discharge capacity of concrete mixer

500 L

混凝土輸送泵電機功率

Concrete transfer pump motor power

45 kw

攪拌電機功率Stirring motor power

18.5 kw

提升電機功率Boost motor power

5.5 kw

水泵電機功率Water pump motor power

0.75 kw

電機轉速Motor speed

1440 r/min

混凝土輸送壓力Concrete transfer pressure

12 MPa

理論混凝土輸送垂直高度

Theoretical vertical height of concrete conveying

150 m

理論混凝土輸送水平距離

Theoretical concrete conveying horizontal distance

500 m

混凝土輸送缸缸徑×行程

Concrete conveying cylinder diameter x stroke

Ф200×1000mm

混凝土主油缸缸徑×行程

Concrete main cylinder diameter × stroke

Ф100×1000mm

控制方式Control mode

遙控器Remote control

分配閥形式Distribution valve form

S管閥 S-pipe valve

液壓油路形式Hydraulic oil circuit form

開式回路 Open loop

潤滑系統Lubrication system

自動潤滑

Automatic lubrication

泵送系統油壓Pumping system oil pressure

32 MPa

攪拌系統油壓Mixing system oil pressure

8 MPa

液壓油箱容積Hydraulic tank volume

450 L

允許混凝土骨料尺寸Allow concrete aggregate size

≤50mm

出料口內徑Discharge port inside diameter

Ф180mm

混凝土輸送管內徑

Inside diameter of concrete conveying pipe

Ф125 mm

設備外形尺寸：長×寬×高

Equipment dimensions: length × width × height

5800×2200×2600mm

設備重量Equipment weight

7500 kg

溫馨提示：人工測量數據，不可避免會有誤差，請您以收到的實物為準
